European-style substation
European-style compact substation with modular compartments for transformer, MV and LV units.
Quick Specifications
Voltage Class
10 / 20 / 35kV
LV Range
0.315 to 0.5kV
Rated Capacity
630 to 5000kVA
Protection
Oil tank IP68, HV/LV chamber IP54
Product Overview
Compared with the simple design of the American-style box transformer substation, the YBW European-style box transformer substation appears stable and generous, and it pays more attention to the combination of tradition and innovation.
It originated in countries such as France and Germany, and began to be widely used in China in the late 1970s.
The European-style box transformer substation is composed of parts such as transformers, high-voltage switchgear, and low-voltage switchgear. Each device is closely connected by cables or other transmission media to form an efficient and stable power system.
It adopts the layout of the "mu" shape or the "pin" shape structure.
The box is not only equipped with conventional medium-voltage switchgear, ring main units, and low-voltage boxes, but also installed with transformers, making the product relatively large in volume.
Enforce Standards
- GB 1094.1-2013: Power transformers
- GB/T 11022-2011: Common technical conditions for high-voltage switchgear and controlgear standards
- GB 7251.1-2013: Low-voltage switchgear and controlgear assemblies
- JG/T 10217-2013: Pad-mounted transformer
Normal Service Condition
- It is used outdoors, and the specific operating conditions are related to the required operating environment of the transformers and switchgear it contains.
Performance Parameters
| No. | Name | Description | Unit | Data |
|---|---|---|---|---|
| 1 | Rated Voltage | HV | kV | 10, 20, 35 |
| LV | kV | 0.315 to 0.5 | ||
| 2 | Rated Capacity | kVA | 630 to 5000 | |
| 3 | No-Load Voltage Regulation | +/- 2 x 2.5% | +/- 2 x 2.5% | |
| 4 | Vector Group | Dyn11, Dyn11yn11, Yd11d11 | ||
| 5 | Insulation Level | Lightning Impulse Withstand Voltage | kV | 75, 125, 200 |
| Power Frequency Withstand Voltage (HV) | kV | 35, 55, 85 | ||
| Power Frequency Withstand Voltage (LV) | kV | 5 | ||
| Secondary Control Loop | kV | 2.0 | ||
| 6 | Noise Level | dB | 60 | |
| 7 | Protection Class | Oil tank IP68, high- and low-voltage chamber IP54 |
