35kV Dry-Type Transformer

35kV Dry-Type Transformer

35kV cast-resin dry-type transformer for demanding industrial and utility applications.

Quick Specifications

Power Rating

50-2500 kVA

Voltage Class

33kV / 35kV / 38.5kV / 0.4kV / 0.415kV / 0.433kV

Insulation

Cast Resin

Application

Commercial / Industrial

Product Overview

This series of dry-type transformers with fillers and thin insulation uses epoxy resin encapsulated coils, making the transformers flame-retardant, fireproof, explosion-proof, maintenance-free, pollution-free, and compact enough for direct installation in the load center.

Meanwhile, the scientific and reasonable design and pouring process give the product lower partial discharge, lower noise, and stronger heat dissipation capacity. Under forced air cooling conditions, it can operate continuously at 140% of the rated load for a long time and can be equipped with an intelligent temperature controller for centralized monitoring and control.

The foil-type coil can solve problems such as high short-circuit stress in low-voltage and large-current windings, unbalanced ampere-turns, poor heat dissipation effect, large winding helix angle, and unstable manual welding quality.

At the same time, the winding ends adopt resin sealing, curing, moisture-proof, and anti-fouling measures, and the copper busbars are automatically welded by argon arc welding.

Applicable Standards

  • GB 1094-2013 Power Transformer
  • GB/T 2900.95 Electrical Terms: Transformers, Voltage Regulators and Reactors
  • GB/T 10228 Technical Parameters and Requirements of Dry Type Power Transformers
  • GB 20052-2020 Power Transformer Energy Efficiency Limit Value and Energy Efficiency Grade
  • IEC 60076 Power Transformer

Normal Service Conditions

  • Installation altitude below 1000 meters.
  • Highest ambient temperature: +40 degrees Celsius.
  • Highest daily average temperature: +20 degrees Celsius.
  • Lowest outdoor temperature: -20 degrees Celsius.

Performance Parameters

SCB10 Series Technical Parameter Table

Rated Capacity (kVA) Voltage Group Vector Group Impedance Voltage (%) No-Load Loss (W) Load Loss 120C (W) No-Load Current (%)
HV (kV) Tap Range LV (kV)
50 33
35
38.5 		±2×2.5% 0.4
0.415
0.433 		Yyn0

or

Dyn11 		6.0 450 1420 2.3
100 680 2090 2.0
160 790 2810 1.5
200 880 3325 1.5
250 990 3800 1.3
315 1170 4510 1.3
400 1370 5410 1.1
500 1520 6650 1.1
630 1860 7690 1.0
800 2160 9120 1.0
1000 2430 10400 0.75
1250 2830 12700 0.75
1600 3240 15400 0.75
2000 3820 18200 0.75
2500 4450 21800 0.75

FAQ

Of course. This product covers the voltage class commonly used in Asian markets. Its highest voltage class is 40.5 kV, so 33 kV is fully within the supported range. We can absolutely manufacture a 33 kV / 0.433 kV version for your project.
